Inteli-Power PD9360V 9300 Series Converter - 60 Amp

Inteli-Power PD9360V 9300 Series Converter - 60 Amp

• Input: 105-130 VAC 60 Hz 1000 Watts / Output: 13.6 VDC – 14.7 VDC, 60 Amps
• Green Light (Flooded Lead Acid Mode) - When charging the battery, the converter will sense voltage on the battery and automatically select the proper operating mode to provide the correct charge level; if voltage drops below a preset level the converter will switch to BOOST mode and the output voltage will increase to approximately 14.4 VDC to rapidly recharge the battery
• Blue Light (Lithium with 2-Stage Charge Mode) – Nominal voltage output of 14.4 VDC; when output current drops below a preset level, the converter switches to IDLE mode and voltage output drops to 13.6VDC
• White Light (AGM Mode) – Nominal voltage output of 14.0 VDC; after a preset time, switches to ABSORPTION mode with output rising to 14.7VDC; when current drops below a preset level, switches to FLOAT mode with output dropping to 13.6VDC
• Magenta Light (Constant Voltage Mode) - Full rated load available for load, battery charging, or both. Nominal voltage output of 13.6 VDC. Caution: do not store vehicle for extended periods in this mode. Caution: do not use to recharge flooded lead/acid batteries while in Lithium (Blue) or AGM (White) mode. When output drops below a preset level, switches to NORMAL mode with output dropping to 13.6VDC. If there is no significant battery usage for 33 hours, the converter switches to STORAGE mode with output dropping to 13.2 VDC; in storage mode, output increases to 14.4 VDC for approximately 15 minutes every 21 hours to help prevent sulfation of the battery plates.
